3D Scanning & Designing a Tube Chassis for a Race Car
Автор: EMS3D
Загружено: 2022-06-07
Просмотров: 4481
Описание:
In this video we 3D scan a prototype tube chassis so we can convert it to 3D CAD. This will then allow us to program a CNC bender and CNC laser cutting machine to make perfect duplicates of our tube chassis.
To learn more, schedule a virtual or on-site demonstration or discuss a 3D scanning or inspection project, fill out this quick form at https://bit.ly/371dkfH or contact us at 877-845-2700.
Quick Video Links
1. Intro 0:48
2. Applying SpeedTarget Tape for 3D scanning 1:55
3. 3D Scanning the tube chassis with the GoSCAN Spark 2:49
4. Creating CAD from the 3D scan data in Design X 6:25
5. Design review 30:22
6. Wrap up 31:02
Special thanks to Elevation DF in Tampa, FL. If you need any metal fabricating work visit www.elevationdf.com or call Alex at 727-643-6045
GoSCAN Spark In-depth demonstration
• Creaform GoSCAN Spark 3D Scanner - In-Dep...
SpeedTarget Tape
• SpeedTarget - A Faster, Easier way to appl...
Design X Basic Tutorial
• 3D Scan Data to CAD Model Using Geomagic D...
