termoz 6H: The efficient countersunk ETICS fixing for board materials

Описание: More about the termoz 6H: https://www.fischer-international.com...

The pre-assembled fischer screw fixing termoz 6H is ideal for fixing pressure-resistant insulation up to 300 mm thick into wood and panel building materials. The special underhead geometry of the anchor plate roughens the surface during the setting process and provides torque-reduced penetration into the insulation. The minimal embedment depth of 24 mm ensures additional fast installation. The termoz 6H can be set sub countersunk as push-through installation e.g. with a cordless screwdriver and the fischer hexagonal setting tool 6H, without pre-drilling. By rotating the disc of the setting tool 6H by 180°, the termoz 6H can be also set flush-to-surface. The plate will then be covered by the included insulation closing plug.

Applications:
■ Attachment of ETICS insulating boards on wooden substructures.
■ Flush installation in ETICS insulating materials e.g. polystyrene and mineral wool.
■ Flush-to-surface installation in pressure-resistant insulation boards.

Your benefits at a glance:
■ The pre-assembled ETICS fixing guar¬antees safe fixing into the substrate.
■ The special geometry under the head of the anchor roughens the surface during the setting process and provides a torque-reduced penetration into the insulation.
■ The use of the setting tool 6H enables a clean fixing. Optionally, the setting tool CS can be used in combination with a special bit.
■ The minimum screw-in depth of 24 mm provides quick installation. Pre-drilling is not necessary.
■ For insulating material thicknesses up to 300 mm.
■ The countersunk mounting guarantees plaster surfaces without any markings.
