Romi E 320B CNC Lathe, 2005- Fanuc 18iTB, Live tooling, Sub Spindle
Автор: Revelation Machinery
Загружено: 2022-06-22
Просмотров: 317
Описание:
Max Cutting Diameter: 12.59”
Swing Over Z Axis Cover: 27.55”
Max Cutting Length: 23.62”
Distance Between Faces of Spindles 41.26”
Main Spindle Nose: A2-8
Spindle Hole Diameter: 3.34”
Bar Capacity: 3.0”
Speed Range: 3 to 3,000 RPM
Second Spindle (Right Spindle)
Rt. Spindle: A2-6
Spindle Hole Diameter: 2.87”
Bar Capacity: 2.5”
Speed Range: 4 to 4500 RPM
Z Axis Travel: 23.82”
X Axis Travel: 8.66”
Y Axis Travel: 3.94” (+2.36-1.57”)
B-Axis Travel: (rt Spindle) 31.1”
C-Axis 0.001: Deg
Rapid Traverse: X/Z/B945 IPM / 1181 IPM
Turret Stations: 12
Milling Tools
Spindle Speed: 5 to 5000 RPM
Milling Power: 5 HP
Index Time: .2 sec
Left Motor: 25 HP
Right Motor: 25 HP
Dimensions: 145” x 75”
Weight: 18,739 lbs
Known Issue: Live tooling belt is broken.
