Best 5.1 Channel Amplifier Board For Home Theater Testing || 7x TDA7294 || IndianXtremeAudio

Описание: In this video, We have recorded testing of 5.1 Amplifier board which we made in previous video. we have made a 5.1 Channel Amplifier Board using TDA7294 Audio Amplifier ICs. On a single board, there's a 5.1 channel amplifier circuit using 7x IC's (TDA7294) out of which 5 IC's are used single ended (90w each) and 2 IC's are used in bridged configuration (180w) for subwoofer channel. Each channel has it's own input and output. This board has very heavy heatsink that is recommended for cooling of these 7 IC's and also There's a FAN mounted onto the PCB with it's own regulated 12V power supply circuit. This board also has inbuilt Rectifier dual supply with 22000uF/63V capacitor on each rail and with fuse protection. The board requires 20-0-20VAC to 24-0-24 VAC Transformer to operate optimally.


--------------------------------------------------------------------------------------------------------------------------------------------------------
.... Link to the Project (download gerber file from the link below).....
https://www.pcbway.com/project/sharep...

OTHER PROJECTS

LM3886 MONO - https://www.pcbway.com/project/sharep...


------------------------------------------------------------------------------------------------------------------------------------------------------

Please support us by liking the project in the above link.😊 we will keep bringing new projects for you all.


SUBSCRIBE TO OUR OTHER CHANNEL
https://www.youtube.com/channel/UC2JL...



BUY PCBs from Flipkart -
https://www.flipkart.com/indian-xtrem...

Price of this board - 4500/- Including Shipping.



Kindly contact us at
8383936916 (Mr.Rahul)
for details and sales
