Fusion 360 Form Mastery - Part 20 - Bridging Multiple Form Bodies Together
Автор: Learn Everything About Design
Загружено: 2022-01-09
Просмотров: 11797
Описание:
In this video we will discuss how to bridge 3 form bodies together and add/remove edges to help control edge flow. This process takes a lot of time and you will find yourself adding and removing edges a lot until you are happy with the design.
Some things to consider:
Try to maintain 4 sides whenever possible.
Triangles are usually better than 5 sided polygons
Look to maintain a nice flow of edges on the design
Don't be afraid to delete and try again.
Here is the dataset after the video. https://a360.co/3tdnvea
I ended up doing a little more work on the patch layout and adding symmetry.
