AKK A3-OSD (4-IN-1) 5.8Ghz, 48Ch, 0.1-25-200mW, 600TVL, 1/4 Cmos, NTSC - Camera, Dipole Antenna, OSD

Описание: AKK A3-OSD: https://goo.gl/YCE9AJ

AKK A3-OSD (4-IN-1) 5.8Ghz, 48Ch, 0.1-25-200mW, 600TVL, 1/4 Cmos, NTSC - Camera, Dipole Antenna, OSD
Transmitter: 5.8GHz, 0.1-25-200mW, 48Ch
Camera: 600TVL, 1/4 Cmos, NTSC
Anetnna: Dipole
OSD: Band, Ch., Freq., Power, Voltage, Name, Time

Tested on:
XK A800: https://goo.gl/Vos9cu
   • XK A800 2.4GHz, 5Ch, RC Airplane with 780m...
MEiSTY 8813: https://goo.gl/zboLxd
   • MEiSTY 8813 2.4GHz, 2Ch, 4WD, 1:12 Scale, ...
MJX Bugs 3 Mini: https://goo.gl/SkXbXY
   • MJX Bugs 3 Mini 2.4GHz, 4Ch, 6 Axis, RC Qu...
Eachine VR D2: https://goo.gl/k8vPir
   • Eachine VR D2 5" FPV Goggles, Dual receive...

Key Features:
Customized callsign available
0.1mW/25mW/200mW power switchable
OSD can display parameters on 5.8GHz FPV goggles or monitors
CH, Band ,FR, voltage and flight time adjustable
OV231 lens perfect for low light

Specification
Output power: 0.1mW / 25mW / 200mW
Input voltage: 3.2-5.5V
Video format: NTSC
Dimensions: 18(L) x 13(W)mm
FOV: 120 degrees
Camera resolution: 600TVL
Frequency: 5.8GHz, 6 bands, 48 channels
Weight: 4.3g

Callsign Setting
The VTX allow display customized username(8-character max).All characters can be 26 English letters and 10 Arabic numbers (Symbol and hyphen is not allowed). Below is character table:
A B C D E F G H I
J K L M N O P Q R S
T U V W X Y Z 0 1 2
3 4 5 6 7 8 9

Frequencies table:
5865 5845 5825 5805 5785 5765 5745 5725
5733 5752 5771 5790 5809 5828 5847 5866
5705 5685 5665 5800 5885 5905 5925 5945
5740 5760 5780 5800 5820 5840 5860 5880
5658 5695 5732 5769 5806 5843 5880 5917
5325 5348 5366 5384 5402 5420 5438 5456

Package Included:
1 x AKK A3-OSD small AIO Camera
1 x Power wire adapter
1 x Manual
