Raspberry Pi Streamer / Player Demo

Описание: Introduction to the DIY Raspberry Pi Streamer / Player (with Allo Boss2 CS43198).

Case：
-Aluminum alloy fabricated with CNC and LASER cut
-Opening at the bottom, can change OS with ease
-Dimensions:215(W) x 100(H) x 245(D)
Power:
-40VA audio grade R-type transformer, 5A output
-Built-in LPS, 0.1% load regulation， 80dB PSRR (120Hz)
-8x Nichicon FW Series capacitors
-Ultra low ESR，CLC filtering topology，WIMA MKP10 and TAN CAP for final decoupling
System：
-5“ 800x480 touch screen
-Latest piCorePlayer 8.1.0 (64bit)
-Enhanced system, replaced with NotoSansCKJ, supports Asian characters
-Main processor is Raspberry Pi 4B (4GB)
DAC：
-Allo Boss2 Cirrus Logic CS43198 32bit/384kHz, supports DoP64
-Built-in dual ultra low noise NDK SDA clocks
-THD+N -114dB
-Copper RCA sockets
Functions:
-Control playback via Logitech Media Server
-Supports NAS (NFS或CIFS protocols)
-Supports Spotify Connect (control via apps）
-Supports Tidal (control via web, limited to premium users only)
-Supports external DAC
-Supports external USB hard drive (Up to 2TB)
-Supports external USB CD playback
-Supports CD rippling (limited to Volumio premium users only)

Kits are now available at:

https://carousell.com/p/1145507551
