C.A.T.S. Software Fire Sprinkler presentation in 3D
Автор: Michael Santiago
Загружено: 2010-06-26
Просмотров: 6105
Описание:
Application
In the practical application, floor plans are first of all referenced. Each layer can also be edited in the referenced floor plan. The height is added to the respective floor plan at exactly the right point.
Due to the flexible layer management, it is possible to subdivide the entire sprinkler construction by floor. All sprinkler components, such as sprinklers, pipelines, pumps, valves, etc., are available in databases.
By clicking on walls or entering a surface, the optimum sprinklers are automatically positioned in the plan in accordance with the VdS rules and NFPA standards, after selecting the sprinkler types, parameters, protection zones and heights.
Alternatively, the sprinklers can also be positioned in terms of reference points and edited with all standard AutoCAD functions, such as Copy, Move, etc.
In addition to the sprinkler types in the available database, it is also possible to create individually configured sprinklers.
