ISONIC 3505, 3507 / Short Range Guided Wave Inspection (SRUT GW): Scanning and Strip Chart Recording
Автор: Sonotron NDT
Загружено: 2021-04-18
Просмотров: 2258
Описание:
ISONIC 3505, 3507 / Short Range Guided Wave Inspection (SRUT GW): Scanning and Strip Chart Recording
Strip chart may be formed out of up to four A-Scans obtained in one emitting / receiving cycle and recorded along the scanning line
For each A-Scan the following parameters may be settled independently on others:
• Timebase: Display Delay and Range
• Gain
• Signal presentation either RF or rectified
• Gates start, width and threshold
• Signal evaluation readout
Each A-Scan represents corresponding section (Region of Interest - ROI) of the material selected along the trace of ultrasonic beam
