Pressure Washing Truck Skid Set Up On a Trailer- Jim's Skid

Описание: Pressure Washing Truck Skid Set Up On a Trailer- Jim's Skid
This is a pressure washing and soft wash skid that we built to fit an 8 ft bed truck.

Call us if you are interested in one of this custom built skids
503-730-2389
https://pressurewashingskids.com/

Pressure washing business secrets, Book a call- https://clarity.fm/timcray

Introducing our premium aluminum pressure washing and soft wash truck skid, available in 6.5 or 8 ft sizes.

Key Features:

Heavy-duty reinforced 8 ft aluminum skid, boasting a 1/4 inch thickness, ladder rack, and two side shelves. Our skids are built with heavier gauge aluminum and extra gussets to support machines mounted to the shelves. (Custom locking surface cleaner rack available for an additional $800)

CRX 8 GPM 3500 PSI pressure washer, delivering exceptional power. (Upgrade to Honda engine available for an additional $800)

Three slim 100-gallon water tanks, featuring extra thickness and lids on each side for easy access. The tanks are recessed on the bottom to allow flush plumbing. 6.5 ft skids come with two slim tanks.

Three manual full-frame aluminum reels with stainless steel manifolds. 8 ft skids include two 18-inch reels and one 12-inch reel. (Upgrade to electric reels, heavy-duty USA-made wiring and lugs, and circuit breaker available for an additional $2000)

Remco 12-volt 7 GPM 100 PSI soft wash pump with viton seals, designed to withstand chemical usage. The higher flow and PSI are more effective for reaching high peaks or shooting greater distances.

Hydro Mixer soft wash mixing system, featuring valves and plumbing designed for long life and compatibility with your pump. Proportional metering valves ensure a higher flow rate, reducing stress on your pump and allowing for greater distance when roof cleaning. (Upgrade to 3/4 mixing valves and check valves available for an additional $300)

Hydrauli-Flex Tech Hose Soft Wash Hose 1/2 with crimped 1/2 NPT fittings, providing durability and reliability over 200 ft.

3-way bleach rinse valve with mounts, barbs, and stainless clamps, prolonging the life of the pump by keeping the system fully rinsed out.

ST-510 soft wash gun with stainless couplers for optimal performance.

Stainless steel 4-nozzle J rod, allowing you to spray multiple patterns effortlessly.

Marine-grade high-quality Interstate battery, built to withstand daily recharging and extended use. Lithium battery upgrade- $799

Hudson Float Valve, automatically shutting off the water when the tank is full and allowing water to fill when needed.

One-inch buffer tank drain assembly, featuring custom crimped hose with a ball valve. This assembly serves to drain the tanks, fill buckets, and act as an emergency wash station.

Heavy-duty aluminum tool box with battery mounts, providing secure storage and easy access.

High-quality Kuri Tec poly braid hose used for all soft wash plumbing.

Buffer tank plumbing complete with Tiger Flex crush-proof suction hose, strainer filter system, banjo fittings, and high-quality stainless clamps.

Every nut, bolt, and washer is rust-resistant stainless steel, ensuring longevity and durability.

Upgraded wiring on the pressure washer to double-insulated 6 AWG wiring.

Upgraded 10 AWG wiring and fuse links on the soft wash system.

Additional Recommended Options:

Basic downstream injector setup with a drop stick installed - $150

Deluxe downstream injector setup with a downstream bypass, General Pump high draw injector, three-way rinse valve, and drop sticks for water and chemical installed - $850

FlowPro installed complete with 3D printed mounts, stainless downstream bypass, and Super Suds Sucker Injector - $1550

Whisper Wash 19" Classic with the upgraded 4-nozzle bar - $999

High draw 30% check valve injector setup - $98

Ball valve swivel featuring the Mosmatic swivel to switch between the surface cleaner and gun, providing comfort and ease of use - $115

Suttner ST-457 Turbo nozzle with quick connect plug - $110

M5DS adjustable pattern nozzle for downstreaming - $85

Downstreaming J rod with 4 different nozzles for low-pressure cleaning and applying chemicals - $63

Sharp Shooter tip for high reach from the ground - $39.99, M5 and Sharp Shooter combo, $175

Chemical-resistant Suttner ST-2315 gun for downstreaming, gun, short stainless lance, and quick connect fittings - $130

Upgrade your pressure washing and soft wash capabilities with our high-quality truck skids, designed to deliver exceptional performance and durability.

We strive to source 95% of the parts we use from the USA.

Shipping can be arranged anywhere in the US. We recommend in-person pickup to provide a demonstration of how to use your new skid and address any questions you may have. Feel free to reach out to us at 503-730-2389 for any inquiries about our pressure washing skids.
