How to Remove and Disassemble an Onity HT24 Lock
Автор: Electronic Locksmith
Загружено: 2017-05-08
Просмотров: 25509
Описание:
How to Remove and Disassemble the Onity HT24 Lock
How to uninstall Onity HT24 lockset from the door block
1. Remove Torx #10 screws from thumb turn and back handle
2. Retract deadbolt
3. Remove thumb turn and back handle
4. Remove cover plate
5. Unplug privacy connector
6. Remove four #2 phillip head screws
7. Straighten privacy wire
8. Remove Onity HT24 front lock from door block
How to disassemble Onity HT24 covers and handle
1. Remove front handle
2. Remove privacy wire
3. Remove 6 torx #10 screws
4. Remove back plate
5. Remove battery insulator
6. Remove 4 torx #10 screws
7. Remove card reader cover
8. Remove torx #10 screw
9. Remove battery cover
There are four major parts:
Motherboard
Clutch Kit
Battery Board
Card Reader
Please view videos on how to uninstall and install the specific components
For more information or to purchase replacement parts, check out https://www.electroniclocksmith.com
