RC Fenestron 3D printed for EC-145 T2
Автор: Dream of flying
Загружено: 2019-05-22
Просмотров: 8922
Описание:
You can download an build your own model from here:
https://cults3d.com/en/3d-model/archi...
material: PLA
extruder diameter for all parts: 0.2mm
layer thickness for all parts: 0.05mm
tested tail rotor speed: up to 11800 1/min
(which corresponds to a main rotor speed of 2850 1/min)
ball-bearings:
7x 3x6x2.5
7x 3x6x2.5 flanged
1x 4x7x2.5
2x 6x10x3
2x 2x7x2,5
4x 1,5x4x1,2
main shaft 4x2x21.9mm
second shaft 2x42mm
screw the gearbox housing
3x M1,6x16 and 3x nuts
Bladeholderscrews
7x M2x10
cover and hinge screws
15x PA1,4x5mm
Musik
Corey B Wills - The Great Machine
