💈Effective contour milling❔ Only END MILL❗️

Описание: ◼ The use of end mills with lengths up to 5D can offer very efficient material removal for depths of cut of up to 100mm.
◼ Modern machines are designed for dynamic machining with shank milling cutters, but it is important in these applications to consider the rigidity of the machine-tool-workpiece clamping system, the performance of the spindle and stepper motors.
◼ This application can push milling efficiency to the top of the machine's performance potential, but must be consistent with the spindle maximum load diagram.
➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖
🏭 ‪@hedelius‬‪@hedelius‬ machines can seamlessly exploit the potential of 20mm billet milling cutters when fitted with 50kw spindles.
➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖
🛠 ø20mm 5D CCR UNI
🛠 CCR.UNI-SA.20,0.35°.Z5.R0,2.HB.EL102 DPX
‪@eCERATIZIT‬
📏Dc (tool diameter): 20mm
📏 z (number of teeth): 5 teeth
📏Vc (cutting speed): 210 m/min
📏fz (feed per tooth): 0.15 mm/z
📏Ap (depth of cut): 100mm
📏Ae (cutting width): 1mm
📏Q (volume of material removed)): 250 cm3/min
📏P (required machine power): 14 kW
📏m (mass of steel removed): 2 Kg/min

🌬 Air cooling
💎Material Tool steel
➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖➖
🔒Part clamped to the workpiece surface by an electro permanent magnet WALMAG MAGNETICS s.r.o. is the ideal choice for clamping plate workpieces.
