WHAT KIND OF CIRCUIT IS THIS? Li-ion Type C battery charging circuit.
Автор: TA1EV
Загружено: 2026-01-15
Просмотров: 781
Описание:
Wireless Electronics #Communication #Long-Distance Communication #Disaster Communication
https://ta1ev.wordpress.com/
TA1EVX,
We can call this a SERIES BMS. VERY USEFUL
VALID FOR MULTI-CELL SERIES CONNECTED BATTERIES. Until now, we have used BMS circuits for single-cell circuits, but this charges them collectively, and it stops charging. It reactivates when the voltage drops. The amperage it provides to the circuit changes.
A perfect circuit for a practical solution. I recommend it to everyone; keep it handy.
You will use it most often for 2s and 3s batteries. Even charging a cordless drill with a mobile phone adapter.
