99 - 04 Odyssey Sliding Door Repair - Middle Roller Assembly - Honda Odyssey Sliding Door DIY

Описание: 99 - 04 Odyssey Sliding Door won't open Repair Middle Roller Assembly doors opening and closing this might be your fix. Sometimes the roller assemblies go bad and cause issues with the doors opening and closing on the Honda Odyssey. This video shows the step by step of the removal and replacement of the Middle Roller Assembly on the Honda Odyssey. I also touch on the operation of the motor and how to set the cable tension on the mechanism.

Odyssey Rear Coolant Hoses:
   • DIY:99 - 04 Honda Odyssey Rear Heater Hose...

When to replace: If your sliding door jumps or has trouble sliding shut.

Part Needed:

EX & LX Part # 72520-S0X-A53 (passenger side)
EX & LX Part # 72560-S0X-A53 (driver’s side)

Tools Needed: 10 and 12mm sockets. Long socket extension. phillips screwdriver. Car jack.
Time Needed: 45 minutes
Difficulty: Medium

WRITTEN STEPS:

Remove rear brake light: Pry open two small plastic access ports and removing two phillips screws. The whole assembly pulls straight back – it takes a bit of effort.
Open the door part way: EX owners, press the door open button, and then turn door switch off from the control panel (left of the steering wheel) when door is partway open. Remove two phillips screws on the small body panel that covers the cable. Remove one bolt from the front of the same panel. These are both on the outside of the van.
Pull off the body panel cover: The next step is to simply pull off the panel you removed the screws from. The panel slides back about two inches and then pulls off exposing the cable.
Support the door: The next step is to support the door. Use a car jack with a 2×4 and a towel to protect the paint. The nice thing about the jack is that it is easy to adjust the height when you reinstall everything.

~For EX model (i.e. electric doors) only ~

Outside the van, use a felt pen of some kind to trace around where the roller assembly mounts onto the inside of the door (this is used for alignment when you put the new one in). Inside of the van, remove or at least pull back slightly the interior side panel between the sliding door and trunk. You need to loosen the door drive cable inside the car only enough so you can remove the cables from the roller on the outside off the car. (this is about a quarter turn clockwise).

Unhook cables & remove the roller assembly.

Install new roller assembly.

~For LX model (i.e. non-electric doors) only ~

Use a felt pen of some kind to trace around where the roller assembly mounts onto the inside of the door(this is used for alignment when you put the new one in).

Remove the roller assembly.

Install new roller assembly.
