Installing a Kicker Motor and Bracket on a 2001 16ft Dauntless Bostonwhaler
Автор: livetofish Outboard Repair
Загружено: 2020-09-27
Просмотров: 13784
Описание:
This particular bracket has a 9.5” vertical travel distance. In order to determine the proper mounting location I had to measure the distance between the upper inside edge of the motors’s mounting clamp to the anti-cavitation plate then subtract two inches. For this motor it was 15”- 2”= 13”+ 9.5” = 23.5”
I marked the total length (23.5”) on a stick and clamped it to the mounting board making sure it was flushed at the top. I aligned the bracket so that the bottom of the stick was 1” above the bottom of the transom and marked my holes with a sharpie making sure the bracket was level.
