AXOMATIC OPTIMA 700 Filler // plastic or metal tube filler

Описание: Brand : AXOMATIC
Quantity : 1
Model : OPTIMA 700
Year : 2004
Weight : 320 kg
Dimensions :
(L x W x H) 0.80 x 0.80 x 2.00 M

Automatic tube welding dosing machine with volumetric dosing unit for liquid, sticky, viscous and pasty products.

Equipped:
Manual feeding of tubes into the bucket.
Tube spot centering station by photocell.
Tray with 7 interchangeable buckets depending on tube dimensions, for transferring tubes to the packaging station.
Bucket formats available with the machine: Diameter 25, 30, 35, 45, 54 mm.
Dosing station by volumetric piston interchangeable according to the desired dosage with stainless steel rotating bushel.
Currently equipped with 3 pistons of different volumes, from 5 ml to 250 ml.
Tube filling station using stainless steel nozzle with drip cutter, currently several nozzle formats depending on the tube diameter type.
Single-envelope conical hopper with a capacity of 40 liters.
Tube heating station using a Leister heater, several formats available depending on the diameter of the tube.
Welding station using heated jaw pliers with water circulation.
Closing station using 1 pair of jaw pliers with the possibility of inserting characters (a complete set of characters supplied with the machine) with water circulation.
Cooling station using air blowing.
Station for cutting the top of the tubes for finishing. Waste collection bin.
Station for automatic evacuation of finished tubes into a chute.
General drive by variable speed motor drive. Protective casings with security on the doors.
Stainless steel frame.

Maximum production:
Approximately 1200 tubes/hour.

Total electrical power:
4 kW
380V

Air consumption: 6 Bars.
Water consumption: 4 liters/hour.
