Mirrorcle MEMS Mirrors - Three Modes of Operation

Описание: In this video, we demonstrate several methods of operating Mirrorcle’s Dual-Axis MEMS Mirrors. These mirrors offer the ability to programmatically control optical beam position and velocity, from dc (static and quasi-static) up to some maximum speed. Of course, these devices are mechanical spring-mass systems with a continuous range of responses, however for this demonstration we simplify this continuum to three modes (or methods) of operation.

These three modes are quasi-static (or point-to-point) mode, resonant-quasistatic mode, and resonant mode.

They are described within several documents and application notes which can be found on our website:
Mirrorcle Docs - https://mirrorcletech.com/documentation/
Mirrorcle MEMS Mirrors - Technical Overview - https://www.mirrorcletech.com/pdf/Mir...
Application Note AN005 - MEMS Mirror Resonant Scanning - https://www.mirrorcletech.com/pdf/AN/...

It is recommended to read over these documents, as this video will cover how to use Mirrorcle's MEMS Mirror Development Kits to employ the modes of operation covered within them.

For sales inquiries, reach out to [email protected]
For existing customer support, reach out to [email protected]

00:00 Introduction
01:09 Dev Kit Setup
02:00 mtidevice.ini File
03:15 Reading Characterization Reports
03:48 Quasi-static (point-to-point) Mode
06:40 Resonant-quasistatic Mode
11:06 Resonant Mode
13:12 Thank you for choosing Mirrorcle
