Cat 6090 Shovel Slew System and Troubleshooting
Автор: Luke Rogers
Загружено: 2021-03-01
Просмотров: 3894
Описание:
In this video we discuss the layout of the hydraulic slew circuit on the 6090, compared to the smaller model machines.
This system has added complexity to other models & we've developed a way to test and diagnose faults related to slewing.
To download this presentation as a pdf click here:
https://drive.google.com/file/d/1hAae...
To download a schematic for this circuit, click here:
https://drive.google.com/file/d/1IWyF...
This includes versions before and after the modification, and a schematic example of slew circuit 1 being tested as described in the video.
