Working:
This is a current sensing Single Phase Preventor that turns OFF the 3 Phase Motor during the loss of supply phase. This product protects the motor against single phasing. It is a mandatory add on to any 3 Phase motor starter.
Features
Current Sensing type
Available in 5 to 12.5 HP
Metal Body
-Motor ON Indication
-Connector type design
-Dry Relay Contacts
Compatible with all 3 Phase Starters
Rating: 5 to 12.5HP
Flyer
Connections
L1, L2 and L3 to incoming 3 Phase Supply
M1, M2 and M3 to the Motor Load
C1 and C2 in series with the holding Contact of the Contactor
Technical Specifications:
3 Phase 440V Incoming Power Supply
Relay Contacts C1 and C2 are Normally Open Dry Contacts
Operating Voltage Range: 220 to 450V AC
Tripping time: Less than 2 seconds
Minimum Holding Current - 5A
Application
Naren Single Phase Preventor Model SP2 is used in the majority of 3 Phase motor starters as a mandatory protection mechanism against single phasing. This product protects the motor quickly responds to single phasing by turning OFF the motor starter instantaneously when the single phasing is detected. It is very compact, economical and easy to install.
This product can be purchased on our website as well
Purchase link
https://narenelectrix.in/shop/home/35...
