How to model in a 3D MicroStation DGN file

Описание: In this video, you will learn how to model in a 3D MicroStation DGN file. You will start from a 2D detail and create a complete 3D model from start to finish. You will learn the power of using AccuDraw in a 3D environment. AccuDraw eliminates the need to create “Construction lines” which speeds up the Modeling process, which saves money! Many other efficient methods for working in MicroStation in general will be demonstrated too.

Chapters:
Start 0:00
MicroStation Version 0:34
Space Bar Customization 0:53
New Recents Tab in MS 2023 1:08
AccuDraw review 1:24
Pacing Circles and Lines 2:18
Working Units Review 2:58
Changing Render Modes 3:30
Dynamic View Rotation 4:19
Drawing Lines 4:54
Using Set Origin Shortcut 5:30
AccuDraw Popup Calculator 6:04
Mirroring Lines 7:18
Trim Multiple 7:36
Next Circles 8:08
Horizontal Lines 8:57
Create Region Tool 11:08
Smart Match (ALT+Data) 11:29
Displayset (Isolate) 12:01
Displayset Clear 12:44
Extrude Solid 12:57
Place Block (Rib) 13:30
Protrude Tool 16:32
Place 3D Hole Tool 17:11
Edit 3D Feature (Hole size) 18:14
