AC Power Outlets in a Van | How to Wire an Inverter to a Breaker Box

Описание: AC Power Outlets in a Van | How to Wire an Inverter to a Breaker Box

The Vankookz Van Conversion Masterclass is Finally Here! - https://vankookz-van-conversion-maste...

83 Page Step By Step Van Conversion Wiring EBook - https://www.vankookz.com/shop/van-con...

FREE step-by-step instructional video guide on how to build your van here - https://www.vankookz.com/diy-ford-tra...

**NOTE** - You do not need to add the additional breakers from the inverter to the breaker box. I did this as an added protection since the van was built for someone else just to cover all corners.

Today we are installing our Aims Power pure sine 2000W inverter to a MidNite Solar breaker box and we will also be wiring two 120-volt AC outlets in the van from the breaker panel. I really enjoy installing all the electrical components in a van conversion and these are easily my favorite steps. Wiring the breaker panel is very straightforward and only takes a few hours.

I will recommend checking out the links below and making sure you have everything ordered and ready to be installed. I had to wait a while to get a few parts and it really delayed the electrical installation and I had to start working on the upper cabinets.

I really liked this power inverter, especially with the auto transfer built-in. I like the idea of being able to charge the unit via shore power. It was also very easy to set up the shore power input.

Be very careful when doing this project always check your connections with a multimeter to see if they are hot. I installed a few kill switches so I could completely kill my system while I was working on this project. You can get seriously injured or die when working with this inverter so take this project seriously. If you have no idea what you are doing call your best electrician friend and have them help you. Or call a licensed professional.

I made this video because I had a hard time finding a video that ran me through the parts I needed for this project as well as the steps to do it. I hope this helps some of you kookz out there.

..::CHAPTERS::..
00:00 - Welcome Back to the Channel Ya Kookz!
00:52 - Aims Power Pure Sine Inverter Install Run Through
02:35 - Wiring a GFCI Inline Fuse
03:02 - Midnite Solar Quad Breaker Box
03:39 - Wiring the Midnite SOlar Breaker Box
03:54 - Wiring Breakers
07:20 - Meeting "Van Code" Using Split Loom
07:48 - Wiring Outlets to Breakers
08:29 - Is Romex OK For Vans?
09:01 - Wiring A MidNite Solar Quad Breaker Box
11:21 - Wiring A 120 Volt AC Outlet in A Van
12:55 - Wiring Shore Power on the AIMS Power Inverter
13:40 - Saftey On/Off Switches for Troubleshooting & Installing Electronics
14:02 - Wiring Power Out From an Inverter to a 120V AC Breaker Box
15:41 - Testing to See if We Did it Right
17:31 - Van Conversion Power System Rundown
18:58 - Sign Up for the Vankookz Masterclass Here! - (https://www.vankookz.com)

--Parts & Tools--
AIMS Power Pure Sine Inverter with Transfer Switch - https://amzn.to/3b2ZwXX
MidNite Solar Breaker Box MNEDC Quad - https://amzn.to/3xzaE6R
MidNite Solar MNEDC15 Circuit Breaker 15A 150VDC - https://amzn.to/3NS5ERw
MidNite Solar MNEDC20 Circuit Breaker 20A 150VDC - https://amzn.to/3HrSMiA
Webber WBGF10 20AMP In-Line GFCI 20AMP 120VAC (2x) - https://amzn.to/3zE2Ymg
MidNite Solar MNSBBN Busbar 180A - https://amzn.to/3QimL0B
MidNite Solar Busbar MNSBB-R - https://amzn.to/3tD9m9G
30W 6.0 Amp 3-Port USB Wall Outlet - https://amzn.to/3NYz7JI
15A GFCI Outlet - https://amzn.to/3zGI7Po
SOK Lithium Batteries - https://www.us.sokbattery.com/product...
Heat Gun - https://amzn.to/3x3SjhH
Wire Cutter - https://amzn.to/3x5sGyr
Wire Strippers - https://amzn.to/3xWv1fD
Wire Connectors - https://amzn.to/3mXEUmF
Marine Cable (12 Gauge Stranded) - https://amzn.to/3LYqE7q
Jacketed Cable (12 Gauge Stranded) - https://amzn.to/3wWchet
15 Amp Flanged Inlet 125V, Shore Power Inlet Plug - https://amzn.to/3HwI7Dk
