LH100 THROTTLE P-SETTINGS GUIDE | 60v CATEGORY

Описание: Cheat Sheet!
0:00 - Intro
0:28 - Tip
0:56 - LH-100 Throttle Module
3:15 - P01: Backlight brightness, level 1 is the darkest, level 3 is the brightest;
3:29 - P02: Mileage unit, 0: KM; 1: MILE;
3:45 - P03: Voltage level: 24V, 36V, 48V, 52v, 60v
4:18 - P04: Sleep time: 0, no sleep; other numbers are sleep time, range: 1-60; unit minute;
4:35 - P05: Power-assisted gear position: 0: 3 gear mode;
4:57 - P06: Wheel diameter: unit, inch; precision: 0.1;
5:11 - P07: Number of speed magnets: range: 0-255;
5:20 - P08: Speed ​​limit: range 0-100km/h, unopened
5:27 - P09: Zero start, non-zero start setting, 0: zero start; 1: non-zero start;
6:08 - P10: Drive mode setting 0: Power-assisted drive (how much power is output by the power-assisted gear, the handlebar is invalid at this time).
1: Electric drive (drive through the handlebar, at this time the assist gear is invalid).
2: Power-assisted drive and electric drive coexist at the same time (the electric drive is invalid in the zero-start state).
P11: Power-assisted sensitivity setting is not enabled
P12: Power-assisted start intensity setting is not activated
P13: Type setting of power-assisted magnetic steel plate is not activated
6:29 - P14: Controller current limit setting default 12A range: 1-20A
6:35 - P15: controller undervoltage value
7:03 - P16: ODO
7:11 - P17: 0: disable cruise, 1: enable cruise; automatic cruise is optional (only valid for No. 2 protocol)
8:30 - P18: Display speed ratio adjustment range: 50%~150%,
8:36 - P19: 0 gear enable bit, 0: including 0 gear, 1: not including 0 gear
P20: 0: No. 2 protocol 1: 5S protocol 2: Standby 3: Standby

8:51 - Visit Us
