High Gain slotted rectangular patch antenna loaded with Circular Split ring Resonator

Описание: 🚀 High Gain Slotted Rectangular Patch Antenna Loaded with Circular Split Ring Resonator (CSRR)

In this video, we present the design and performance analysis of a high-gain slotted rectangular microstrip patch antenna enhanced using a Circular Split Ring Resonator (CSRR). By introducing slots on the patch and integrating a CSRR (metamaterial resonator), the antenna performance can be improved in terms of gain, impedance matching, bandwidth control, and radiation characteristics making it suitable for modern wireless applications.

Publisher: Jack Sparrow Publishers
Journal : International Journal of Research and Development in Engineering Sciences (IJRDES)
e-ISSN: 2582-4201 , www.ijrdes.com

Paper Link : https://ijrdes.com/paper-view/high-ga...
DOI : https://doi.org/10.63328/IJRDES-V7RI6P2

Abstract: Design and analysis of a circular split-ring resonator (CSRR) loaded high-gain slotted rectangular microstrip patch antenna (RPA) exhibiting frequency notch characteristics. The primary objective of this work is to enhance the gain and bandwidth of the conventional microstrip patch antenna operating in the X-band. The CSRR structure, functioning as a metamaterial, is incorporated onto the patch to achieve the desired electromagnetic response. The proposed antenna attains dual gain peaks of 20.1 dBi and 12.0 dBi, exhibits a stable radiation pattern, and resonates at 10.76 GHz with a return loss (S11) of -18.94 dB. Owing to its high gain performance and operation within the X-band, the antenna demonstrates strong potential for satellite communication applications.

✅ What you’ll see in this video:

Rectangular patch antenna design basics
Why slotting improves resonance and current distribution
How CSRR loading modifies effective permittivity/permeability
Return loss (S11), VSWR, bandwidth analysis
Radiation pattern, gain, directivity, efficiency results
Surface current distribution & field plots explanation
Comparison: With vs Without CSRR (performance improvement)
