Numerical 03 : In a simple screw jack, the pitch of the screw is 10 mm and length of the handle is 450 mm find V.R. if an effort of 25 N is applied at the end of handle can lift the load of 3 kN. Find the efficiency of the screw jack. Also calculate amount of effort lost in friction.
