Speaker 1: Today on our 2018 Chrysler Pacifica, we're going to be taking a look at, I'm going to show you how to install, the Curt T-Connector vehicle wiring harness with 4-pole flat trailer connect. Part number C56322. Here's what you're going to get in your kit. You're going to get your wiring harness. Going to give you yours plugs that are going to plug into existing wiring. This is going to be for your passenger side.

This is going to be for your driver's side and they're going to plug in right behind your taillights. And your 4-pole connection. This is going to give you all your proper riding functions to safely tow your trailer. Both turn signals, your running lights, your brake lights, and also your grounds.Now, we get a lot of questions about why you need a converter box. Well, the converter box is a very important part of the wiring.

What it's going to do, it's going to protect your factory wiring from any back feed if your trailer has a short. You're going to get the fuse, fuse holder, fuse zip ties, two-sided sticky tape for mounting your converter box, give you a ring terminal. You're also going to get two butt connectors. Since our wiring is going to be living outside, I suggest not using those and using heat-shrink butt connectors. You can pick these up, these are part number DW05745.First thing we're going to do is we're going to take a T27 Torx bit and we're going to remove our factory taillights.

We're going to have two bolts on that hold each one in. We're going to take our light and we're going to pull straight back with it. Just like that. Go ahead and unplug it. You're going to have a red tab there.

Push up on it like that. And then we're going to push down right there on section and then pull out. We're going to do the same thing with the passenger side.Next I'm going to take an airline tube. You can use a wire hanger. We're going to feed it right down through this spot here, down to the bottom of the vehicle. Now, on the underside, you have the underbody panel. Take an eight-millimeter socket. We're going to remove this bolt, this one and this one. We just need to pull down this corner to get our wiring up. Then you can see, there's my tube.Now, since we have such a small space to go through up there, do your wire like this. You're going to take one end and you're going to tape it to whatever you have dropped down through there. Make sure you tape it straight up and down and not across. Now, before we make our connection, I'm going to take a little bit of dielectric grease. Go ahead and put it on your connections. It's going to help prevent any moisture build-up inside. It's going to help protect your connections from corroding. Make sure you push your red tab back down and then we'll reinstall our taillight.Next, I'm going to mount my converter box. Take our two-sided tape, push it firmly into place and peel off the other side. Now, I'm actually going to stick this, because we have a panel, I'm going to stick it right on the side of my hitch right here. Put a little pressure on it, make sure it's going to stick on there. Then we just run our wires right over the top. I'm going to strip back my black wire here. You're going to have black wire that comes in your kit, and I'm going to strip back the end of that. Take our heat-shrink butt connector and we'll clip the two together. We'll take a heat source and we'll shrink the butt connector.I'm going to take my self-tightening screw with a quarter-inch socket. I'm actually going to mount it right on my frame rail. Right there. You want to make sure that it's on metal and not on any plastic. Now, since my black wire is going to be running through the front of the vehicle, while my panel is down and loose, I'm going to go ahead and feed it through to the other side of it. Now, we can go ahead and put our panel back in place. I'm just taking some zip ties and running my 4-4 wire to my bracket. Then my green wire, I'm going to run it across over to my passenger side, and I'll just zip tie it around the back of my hitch.So, here on the passenger side, since we have the exhaust here, we don't want a wire to run right over top of it. We want to try to stay away from our heat. So, what I did is I pushed my connectors over top of my bumper beam here and then when I pull my wire down, it'll come down over here and it'll keep my electrical wire well up above my heat.
