Solidworks assembly tutorials | Model Bench Vice Assembly (Top down assembly approach])
Автор: CAD & FEA Tutorials
Загружено: 2022-09-06
Просмотров: 2077
Описание:
This is a complete solidworks tutorial to model a bench vice assembly in solidworks using top down assembly modeling approach.
In top-down assembly design, one or more parts are defined within an assembly. The design intent comes from the top, which is the assembly, and moves down to the parts.
We will model bench vice base part first then other parts of vice like Yoke and Pin will be modeled within assembly mode of Solidworks
And in the last, we will use float feature to add assembly mates.
