Abaqus Explosion Simulation Tutorial | 100 kg TNT on Concrete Wall (CONWEP Explained) - Step by Step

Описание: In this tutorial, we perform a blast simulation of a concrete wall in Abaqus/Explicit using the CONWEP air-blast model. The video covers both the practical modelling steps and the core blast mechanics concepts behind the simulation.

We model a 50 m × 50 m concrete wall with a window opening and apply a 100 kg TNT explosion at a 10 m stand-off distance. The tutorial explains how blast pressure is generated, how cracking is modelled, and how structural response evolves under dynamic loading.

What you will learn

How CONWEP blast loading works in Abaqus

Difference between pressure loading and incident wave

How to define brittle cracking and shear retention

Setting up material properties for concrete

Choosing appropriate TNT mass and stand-off distance

Running a Dynamic Explicit blast simulation

Interpreting deformation and cracking results

This tutorial is ideal for:

Mechanical and civil engineering students

FEA engineers

Researchers working on blast or impact problems

Anyone learning Abaqus Explicit

Model details used in the tutorial

Wall: 50 m × 50 m × 0.2 m

Window opening: 10 m × 10 m

TNT charge: 100 kg

Stand-off distance: 10 m

Unit system: m–kg–s–Pa

Solver: Abaqus/Explicit

Blast model: CONWEP air blast

Related topics

Blast-resistant structures

Dynamic structural response

Concrete cracking under explosion

Explicit finite element analysis
