A CT kWh meter combines the functionality of current transformers and kilowatt-hour meters. Current transformers are used to step down high current flow to a more manageable level, while kilowatt-hour meters measure energy consumption.

Proper wiring of current transformers to single-phase kilowatt-hour meters is essential for accurate energy measurement and effective energy management in electrical systems.

By following these steps, you can ensure reliable data collection and efficient energy usage.
1.Turn off the power.
2.Identify and mark the phase wires accordingly.
3.Slide the CT over each phase wire. Make sure to connect the correct polarity.
4.Connect the CT wires to the appropriate meter ports.
5.Connect up each electric meter in series.
6.Connect the neutral wire to the device as shown in the wiring diagram.
