Booth's Algorithm is a crucial topic in Computer Organization and Architecture (COA) for the GATE CSE exam. It is an efficient method for multiplying signed binary numbers in 2's complement representation, reducing the number of addition/subtraction operations compared to traditional methods.
GeeksforGeeks
GeeksforGeeks
+1
Here is a comprehensive guide to Booth's Algorithm for GATE CSE, including key concepts, examples, and relevant hashtags.
Relevant Hashtags for GATE CSE
#GateCse #COA #ComputerOrganization #BoothsAlgorithm #DigitalLogic #ComputerArchitecture #GatePreparation #BinaryMultiplication #SignedNumbers
Core Concepts of Booth's Algorithm
Purpose: Multiplies two signed binary numbers (multiplier and multiplicand).
Mechanism: Examines pairs of bits in the multiplier (
) to determine whether to add, subtract, or do nothing, followed by an arithmetic shift right.
Handling Negatives: Works automatically on 2's complement, making it ideal for signed arithmetic.
Implicit Bit: An extra bit (
or
) is initialized to 0 and appended to the right of the multiplier.
GeeksforGeeks
GeeksforGeeks
+4
Booth's Algorithm Rules (Steps)
For each pair of bits
in the multiplier:
00 or 11: No operation (No add/sub). Arithmetic Shift Right (ASR).
01: Add Multiplicand (M) to Accumulator (A). Then ASR.
10: Subtract Multiplicand (M) from Accumulator (A). Then ASR.
Shift: Perform Arithmetic Shift Right (ASR) on
. The sign bit of
is preserved.
Iteration: Repeat
times for an
-bit multiplier.
GeeksforGeeks
GeeksforGeeks
+4
Example:
(Using 4-bit representation)
Multiplicand (M):
Multiplier (Q):

(2's complement):
Step AC QR
Action
Initial 0000 1100 0 -
1 0000 1100 0
ASR
0000 0110 0 -
2 0000 0110 0
ASR
0000 0011 0 -
3 0000 0011 0
ASR
1101 0011 0 -
1110 1001 1 -
4 1110 1001 1
ASR
1111 0100 1 -
Result:
Commonly Asked GATE Questions & Tips
Worst-Case Scenario: A multiplier with alternating zeros and ones (e.g.,
) causes maximum additions/subtractions, leading to poor performance.
Best-Case Scenario: Continuous blocks of 1s or 0s.
Bit Length: If the multiplier is
bits, the algorithm requires
iterations.
Modified Booth's Algorithm (Radix-4): Used for higher speed, it examines 3 bits at a time, reducing the number of partial products to
.
YouTube
YouTube
+4
Resources to Study
Neso Academy: Excellent for understanding the step-by-step implementation.
Ravindrababu Ravula: Focuses on the logic behind the algorithm.
GeeksforGeeks: Good for practice problems and rules.
GATE Overflow: For past year questions (PYQs) and discussions on 1996, 2005, and 2008 questions.
