GS Tutorials - VLAN Configuration - GWN Series

Описание: Grandstream Tutorial - VLAN Configuration - GWN Series

In this video, we will explain how to configure VLANs on the Grandstream networking and UC solutions. Throughout this tutorial, we will demonstrate VLAN configuration on the GWN router, switch, and access point. We will also explain the different methods to assign voice VLAN to endpoints such as IP phones.

For specific details please check out the chapter list below.
00:38 Configuration diagram
01:30 VLAN configuration on the GWN router
03:25 VLAN configuration on the GWN switch
07:02 VLAN configuration on the GWN access point
08:46 - Voice VLAN configuration methods
09:45 - Voice VLAN configuration: Tagged voice VLAN using LLDP
11:50 - Voice VLAN configuration: Untagged voice VLAN using LLDP
12:44 - Voice VLAN configuration: Auto voice VLAN using LLDP
14:46 - Voice VLAN configuration: Untagged OUI
17:06 - Voice VLAN configuration: Tagged OUI

Please note that while the user interface may undergo occasional changes through firmware updates, the core configuration and functionality will remain consistent.

The device models used in this tutorial are:
GWN7002 firmware version 1.0.5.35
GWN7803P firmware version 1.0.5.61
GWN7660 firmware version 1.0.25.33

Please refer to the links below for additional information about this tutorial

VLAN Configuration Guide:
https://documentation.grandstream.com...

Voice VLAN configuration Guide:
https://documentation.grandstream.com...

QoS configuration on the GWN switches:
   • Video Guide - QoS - GWN780x Series - Part 7

LLDP configuration on the GWN switches:
   • Video Guides - LLDP - GWN780x Series - Part 6
