digital counter(0-9) by 7-segment , 4026 ,555 IC's
Автор: Electro Oxe
Загружено: 2021-02-04
Просмотров: 6767
Описание:
This video is about the digital counter from (0-9) by 7 segment display, for that we used CD4026 IC, is an IC which can perform the function of both a counter as well a 7-segment Driver. One single IC can be used to count form zero (0) to nine (9) directly on a Common Cathode type 7-segment display. The count can be increased by simply giving a high clock pulse; also more than one digit (0-9) can be created by cascading more than one CD4026 IC. For clock we using 555 ic.
required stuff:
1.bread board
2.555 IC
3.CD4026 IC
4.push botton switch
5.1k ohms
6. connectors
Circuit diagram: https://bit.ly/3u9ZWjv
