Machine Elements: Four-Bar Linkage Part 2 | Analytical method (Problem 1-1)
Автор: MasterME
Загружено: 2021-09-11
Просмотров: 8277
Описание:
This video presents the analytical method of solving the extreme positions of a four-bar linkage of Problem 1-1 from the book of James and Doughtie, Elements of Mechanism.
Microsoft Excel was used to speed up the calculations and results were verified using Fusion 360. Also, graphical and analytical solutions were compared.
Excel file can be downloaded thru this link: https://docs.google.com/spreadsheets/...
Part 1: • Machine Elements: Four-Bar Linkage (Filipi...
Contents:
0:00 Introduction
0:40 Analytical method
9:04 Verification of result using Fusion 360
11:04 Comparison of results
Please visit our channel for more tutorials
Channel link: / @masterme3791
Please use the comment section for any questions/requests/suggestions or send your email to [email protected].
You can also message us thru our Facebook page / mechanical-and-electrical-engineering-educ...
