GENEVA WHEEL MECHANISM - 3 BASE - SOLIDWORKS
Автор: DESIGN DRAGON
Загружено: 2022-10-01
Просмотров: 112
Описание:
The rotating drive wheel is usually equipped with a pin that reaches into a slot located in the other wheel (driven wheel) that advances it by one step at a time. The drive wheel also has an elevated circular blocking disc that "locks" the rotating driven wheel in position between steps.
One application of the Geneva drive is in film movie projectors and movie cameras, where the film is pulled through an exposure gate with periodic starts and stops
for design related questions / for new design mail to : [email protected]
