UWL 816 Walkthrough

Описание: The UWL 816 Wheel Loader is a versatile and robust piece of machinery designed for various heavy-duty tasks including landscaping, bulk/material handling, and snow removal. Below is a detailed description based on its specifications:

UWL 816 Wheel Loader

Operating Weight: 3.9 tonnes (8670 lbs)

Engine:

• Model: Cummins QSF 2.8
• Type: 4-cylinder in-line direct injection
• Power: 64 hp (48 kW) at 2500 rpm
• Displacement: 2.8 liters
• Fuel Consumption: 4.2 liters per hour
• Maximum Torque: 185 N.m

Transmission:

• Type: Hydraulic Torque Converter
• Gear Shift: Automatic
• Pattern: F2 / R2
• Axle: HD Hub Reduction Z10

Steering:

• Type: Full-hydraulic articulated steering
• Steering Angle: 42 degrees
• Working Pressure: 1740 PSI

Dimensions:

• Length (Bucket on Ground): 4953 mm (16’ 3”)
• Width (Outside Tyres): 1178 mm (5’ 10”)
• Height: 2438 mm (8’)
• Bucket Width: 1829 mm (6’)
• Max. Dump Height: 2184 mm (7’ 2”)
• Max. Lift Height: 3556 mm (11’ 8”)
• Max. Height to Center Pivot Pin: 3048 mm (10’)
• Center to Rear Wheel: 1143 mm (3’ 9”)
• Center to Front Wheel: 1143 mm (3’ 9”)
• Center to Quick Hitch: 2387 mm (7’ 10”)
• Dump Distance: 508 mm (1’ 8”)

Hydraulics:

• Type: Gear Driven Hydraulic Pump
• Flow Rate: 42.4 Lpm (11.2 GPM)
• Working Pressure: 2900 PSI
• Lifting Cycle Time: 9 Seconds
• Control: Hydraulic Joystick

Capabilities:

• Safe Work Load: 1.5 tonnes (3300 lbs)
• Breakout Force: ≤ 3.85 tonnes (8500 lbs)
• Bucket Capacity: 21 cubic feet (0.59 m³)
• Tyre Specification: 20.5 / 70 / 16

Features:

• Cummins 64hp diesel engine
• All-wheel drive with AC/heater for all-season use
• Articulated oscillating floating function suitable for both agricultural and construction work
• 42° articulation for working in tight spaces
• Radio/Bluetooth player with stereo speakers
• Bobcat quick hitch compatible with various attachments such as snowplows, grapples, and 4-in-1 buckets

Contact Information:

• Phone: +1 (800) 580-7316 Poste #2
• Email: [email protected]
• Quebec Branch: 505 Boulevard Saint Jean Baptiste, Mercier,
J6R 2A9
This compact yet powerful wheel loader is engineered for efficiency and versatility, making it an ideal choice for a variety of operational needs.
