Toggle clamping double station blow molding machine for 1 gallon HDPE bottle
Автор: Susan Xu
Загружено: 2018-10-17
Просмотров: 1424
Описание:
Toggle clamping system double station blow molding machine for 1 gallon HDPE bottle.
Screw diameter 70mm
Screw L/D 24：1
Extrude motor 380V-50HZ 22kw-4 SIEMENS BEIDE
Screw rotate speed 8-80r.p.m
Screw heating power 13kw
Inverter DELTA（Heavy load）
Num of Heating zone with air cooler 3 zone
Extruding volume 70 Kg/h（HDPE）
Heating Power 4*3（=12kw）
Safety protection Safe door
Feeding section with forced cooling have
Liner Guide TAIWAN HIWIN
Mould plate size 360（W）X490（H）
Mould size 380（W）×450mm(H)
Clamping force 80KN
Plate opening stroke 250-550mm
Carriage movement stroke 460mm
Mold min. thickness 260mm
Clamping system stroke inspect Proximity switch
Clamping system support part Linear guide
For more details , Please contact Ms. Susan
Mobile / whatsapp: +86 139 1569 7401
Email: [email protected]
Skype: susan821123
