Operation Guide: How to Replace the Galvanometer Scanner Mirrors & How to Calibrate it ?

Описание: This video will provide you with more details about how to replace the galvanometer scanner mirrors and how to calibrate it.

00:00 - Opening Screen
00:04- Galvo Motors & mirrors
00:10 - Remove the Galvanometer Housing
00:22 - Record the Original X Y-axis Motor Height
00:25 - Remove the Drive Board & Rainbow Cable
00:32 - Remove the X Y-axis Motors
00:43 - Remove the X Y Mirrors
00:50 - Install the new X Y Mirrors
01:00- Connect the X Y Motors to the Drive Board
01:09- Install the Galvanometer Housing
01:14- Level Calibrate
01:18- Install X Y Motor
01:34- Power on Test
01:44-Confirm the mirrors has self-locked
01:50-Switch on the laser
01:56-Install the Field Lens
02:07-Adjust the X Y Motors ' Height
02:12-Start the Machine & Calibration by Line
02:20- Install the Drive Board
02:50- Install the Upper Cover
03:00-Test
