SOFISTIK Analysis and Design for Revit part 3
Автор: BIM DRCONGO
Загружено: 2021-01-01
Просмотров: 1230
Описание:
Organization of multiple analysis models derived from central building model
The analysis of a structure usually involves multiple analysis models of different fidelity. A global
(often simplified) model of the 3D-structure is being used for global load take down or dynamic
analysis. Local models are used for detailed analysis or member design. For example, the
design of a column is carried out on a separated model by usually taking geometric and material
nonlinear effects into regard. Similarly, the reinforcement design of slab members is often
performed by separating the slabs from the global model. This class will show a workflow,
where analysis variants can be set up within different views from which they can be analysed by
the SOFiSTiK Extension. It will also be shown, how local modifications being subject to only one
single model can be set up using Design Options within Revit. This will be demonstrated by
loads being transferred from one sub-model to another.
