Spiral Flexible Aluminum Duct Forming Machine

Описание: The Spiral flexible aluminum duct making machine is used to produce the flexible aluminum duct, which is widely used for chimney, exhaust pipe, etc.
HVAC air duct Semi-rigid pure aluminum flexible duct forming making machine PAD-300 for chimney tube manufacturing.
pure aluminum pipe making machine is specially for producing aluminum flexible ducts with pure aluminum foil without steel wire reinforcement for various purpose. pure aluminum pipe making machine is automatically, and unnecessary to change roller or mold for different diameter. The finished ducts can be insulated with glass wool used in the HVAC system.
Main Features
1) Auto cutting functions optional .

2) Vacuum compressing option Or Full automatic model option. (For save manpower)

3) The patterns and lock seam can be customized .
Special customized:

The tube forming style (lock seam) can be European and American standards .
The vacuum model compressor can help to pack the tubes easily.
The round tube can be processing to rectangular shape to fit the special usage .
The rectangular shape tubes Commonly used in the air conditioning system of buses, RV, rail cars, yachts and villas.
The diameters range following customers requirements. (Chimney, Dryer hoses)
Plastic with Aluminum Flexible Duct Forming Machine Manufacture
Plastic and aluminum flexible duct machine

The Plastic and aluminum flexible duct machine is used to produce aluminum flexible ducts with aluminum foil or metalized PET film with steel wire reinforcement

Main technical data

1.1 Diameter range: 80mm~600mm

1.2 Length of aluminum tube: 1-10m

1.3 Raw material: metalized PET film, 0.012mm, width 35-50mm

1.4 Dimension (L x W x H): 2200 x 820 x 1550mm

1.5 Weight: 500kg

1.6 Main motor power: 1.5kW

1.7 Temperaute: 40~120 centigrade

1.8 Electric heating power: 2.4kW

1.9 Working speed: 1-35 m/min, adjutable

1.10 Features of finished ducts:

Temperature resistance: -30°C-140°C

Max. air flux: 30m/s

Max. working pressure: 2500Pa

Pitch between corrugations: 20mm
