Determine the average shear stress developed in pin A and D. Engineers Academy

Описание: SUBSCRIBE my Channel for more problem Solutions!

Mechanics of materials by R.C. Hibbeler
Chapter 1
Stress

1-43. The 150-kg bucket is suspended from end E of the frame. Determine the average normal stress in the 6-mm diameter wire CF and the 15-mm diameter short strut BD.
*1-44. The 150-kg bucket is suspended from end E of the frame. If the diameters of the pins at A and D are 6 mm and 10 mm, respectively, determine the average shear stress developed in these pins. Each pin is subjected to double shear.
