DIY ESP8266 Pedal Assist for eBike controller with no PAS

Описание: You may have an eBike controller without a Pedal Assist system. If you have a Home Assistant running at your house and if you have a ESP-module (ESP8266, ESP32 etc). You can easily make a programmable DIY Pedal Assist System using ESPHome firmware and my YAML code!

See how to flash ESPHome firmware:    • How to flash ESPHome on Linux | esphomefla...

YAML CONFIG:


esphome:
name: pas
platform: ESP8266
board: d1_mini
on_boot:
priority: 850
then:
output.set_level:
id: pwm_output1
level: 0%

wifi:
ssid: "XXXXX"
password: "XXXXXX"
manual_ip:
static_ip: 192.168.3.117
gateway: 192.168.3.1
subnet: 255.255.255.0

logger:

api:
reboot_timeout: 120min

ota:

sensor:
platform: pulse_counter
pin: D1
id: pulsesens
update_interval: 1s
on_value_range:
below: 1100
above: 175
then:
output.turn_on: pwm_output1
above: 1100
then:
output.turn_off: pwm_output1
below: 175
then:
output.turn_off: pwm_output1
internal_filter: 4us
count_mode:
rising_edge: DISABLE
falling_edge: INCREMENT

output:
platform: esp8266_pwm
pin: D5
max_power: 28%
frequency: 2800 Hz
id: pwm_output1



Check out these awesome websites:

https://www.home-assistant.io/hassio/
https://esphome.io/
https://github.com/esphome/ESPHome-Fl...

Please tell me in the comments if you have any questions.
