How to convert rotational motion into linear motion | Lemurian Designs
Автор: Lemurian D-Signs
Загружено: 2020-04-09
Просмотров: 61014
Описание:
Mechanisms used for converting rotational motion into linear or reciprocating motion
1. Linear motion perpendicular to rotational axis
(i). Slider crank mechanism
(ii). Scotch yoke mechanism
(iii). Crank and slotted lever quick return mechanism
(iv). Cam and follower motions - Knife edge, roller and flat face followers with disc cam.
(v). Rack and pinion
2. Linear motion parallel to rotational axis
(i). Cylindrical cam
(ii). Lead screw assembly.
Visit our channel for watching more engineering videos like projects, software tutorials, working principles, subjects visual learning, job related videos, business, engineering related puzzles and more topics.
