090 FreeCAD 0.20 PDWrapper Macro 3D Offsetting
Автор: Mark Ganson
Загружено: 2022-01-18
Просмотров: 699
Описание:
In this video I am trying to help a user on the forum with a file, cutting a gear from another gear. Here is a link to the discussion.
https://forum.freecadweb.org/viewtopi...
You can find the file I used as a starting point in that discussion thread. It's version 2. This file will be version 3 and it can also be gotten from my github repo at:
https://github.com/mwganson/youtube_m...
PDWrapper macro allows for using solids created in other workbenches inside a Part Design Body. It can also be used, as here, to wrap a Part Design native object, and do things like 3D offsetting, 3D scaling, changing from additive to subtractive types, and dynamically enabling/disabling certain features within the Body.
It's a very powerful macro, and also very complicated to use. I will be making more videos in the future about this macro.
