MAKING A RADIAL ENGINE FROM A PICTURE ON THE INTERNET? | 4-AXIS CNC! PART 1
Автор: STITCHED UP BUILDS
Загружено: 2022-08-04
Просмотров: 4377
Описание:
We build a wwII style plane engine from scratch using a CNC lathe.
This is our fist video so any suggestions on what you would like to see
(Built or filmed) would be greatly appreciated!
Machine: Okuma LB3000 space turn
Let us know in the comments if you want us to release a 30minute version of real time machining + extra shots and the full length interview with all the gritty details?
A big thank you to "wolfgang gutleb" for making the design free on grabcad.com
Part 2 will be running the engine on hobby fuel!
www.reddit.com/r/STITCHEDUPENGINEERING/
Instagram: Stitched up builds
0:00 Teaser
0:04 Machining Start
0:20 Crank Case/Body
4:20 Cylinders, Heads & Sleeves
5:08 Pistons
5:44 Conrods (Connecting rods)
6:26 Crank Shaft
7:45 Valve Assembly
8:16 Pushrods
9:34 Gears
9:04 Cam Wheels
9:51 Cam Housing
10:56 Full Assembly stop motion
11:22 Running/Testing Clearances & Timing
12:10 Next Time On Stitched Up!
12:41 Tell Us What You Want To See Us Make
