Amiga Series #1 - How I did build an Amiga Mouse from an optical PC Mouse
Автор: redcatimaging
Загружено: 2022-07-15
Просмотров: 1640
Описание:
In this Video I show and explain to you, how I did build a new Amiga Mouse from an old optical PC Mouse.
I had a Logitech M-BJ58 which is perfect for this (I did not test the other mouse with the H2000 chip, but from the datasheet it looks similar).
Basically you will need a new Cable with a 9 pin Amiga mouse plug and a mouse with a H2051 optical sensor chip (others might work too), which provides the signals the Amiga needs. The Mouse buttons have to connect on one side to ground.
A very easy mod and a fun project if you are missing a mouse for the Amiga or just need/want a new optical one.
Please always check your work and don't plug in into your computer if you are in doubt if everything is connected properly! You do this on your own risk!
Have fun building, Foxxy :).
