E4G AMGO A240 4 ton, 2 post Baseplate lift

Описание: E4G A240 PEAK 2 Post Lift 4 Ton
The A240 2 post 4 ton lift is the latest addition to our Amgo lift range. Now with 4 x 3 stage arms. Amgo is the new European brand name for Peak lifts. Hi-spec features makes this lift one of the best on the market.

https://www.garageequipment.co.uk/veh...

E4G A240 Specification:
Lifting Capacity 4.0 Ton
Lifting Height: 1825 - 1960mm
Lifting Time: 45 seconds
Motor: 3.0hp
Power: Single Phase 230V 20amps (Three Phase also available)
Gross Weight: 624Kg
Overall Length: 3479mm
Overall Height: 2742mm
Overall Width: 3350mm
Minumum Pad Height: 100mm
Minimum depth of 150mm / 6 inches of concrete is required to install
Main Features:
24V control system
Chain-driven
Dual hydraulic cylinders
Single-point safety release and dual safety design
Super-symmetric arm design with three-stage front and rear arms

Additional Features:
Screw and stackable superior rubber lift pads complete with a set of stackable 3” adapters
Automatic arms restraints 3/8” aircraft quality cable is used for synchronization
Safety curtain protection on columns
Safety toe bars
Parts tray on arms
Rubber door protection


Additional Information:

CE Approved
Spares back up
We can install or can be collected
5 year warranty on Steel, 2 years on hydraulics and 1 year on electrics

Optional Extras:
Optional baseplate extension E4G 20801
