Nargesa H1-H2-H4 Industrial Propane Gas Furnace Forges for Artistic Forging Quantum Machinery Group

Описание: Furnace for Artistic Forging H1-H2-H4 NARGESA, fabricated with up to four burners to heat up iron and allow its moulding, bending, piercing , welding and treatment...

Propane Gas Forge H4 NARGESA, was designed to heat steel parts. It's used in blacksmith workshops for ornamental forge, moulding iron up to achieving the desired shapes end forging, horseshoeing, treatment of parts... It is a good substitute for the ancient Forge.

TECHNICAL FEATURES
• Nargesa offers Gas Forges that can have up to 4 active burners.
• All burners may work independently. There´s no need to make them work altogether.
• Working temperature, 1300ºC.
• Adjustable pressure from 0.5 to 2 Bar.
• Maximum consumption 1 Kg/h. per burner (x4).
• Propane gas supply.
• Combustion chamber isolated by ceramic fibre and refractory brick.
• Useful inner cavity: 280mm width x 100mm height and 470mm depth.
• Removable back door to heat up steel bars in the middle.
• Maximum capacity Ø 80mm.

Main advantages of using a propane gas furnace instead of a conventional carbon forge:
• Fast reaching of working temperature.
• It's clean and it does not produce harmful emissions for health.
• Easy ignition.
• Possibility of moving it to the working site:

Safety components:
• Pressure reducer between the tank and the supply hose.
• Flame check valve.
• Thermal device valve: It cancels the gas supply in case of detecting anomaly.
• Adjustable safety metal screen at the front part. It allows dodging any metal projections that might occur.
• All components are standard and easy to get at any shop or hardware store.
• Furnace Nargesa H1-H2-H4 is delivered completely mounted.

Its simplicity, dimensions, easy ignition and fast reaching of optimum working temperature, make it a very versatile furnace.
Forging furnaces H1, H2 and H4 are according to the European directives and regulation of manufacturing. CE

Use Nargesa gas forges for all kind of ornamental forging, to make horseshoes, roll up the snail forged shaped, iron mold, endtreatment of parts,...
You may combine both, Nargesa Furnaces and Power hammers MP50 and MP60 and End Hot Forging Machines NF70 and PC16, to achieve a lot of ornamental shapes with minimum effort and maximum speed.
