Case Packer For Rice Cartons - Top Load Model TT-1200T - Tishma Technologies

Описание: #casepacker #packaging #automation #packagingmachinery

Learn more about carton packaging automation:
https://www.tminn.com/en/solutions/ca...

The TT-1200 is an intermittent motion case packer that can reach speeds up to 20 cases per minute, and this specific application packs at 5 cases per minute. It is designed and built for case packing of rice cartons in a 2×6 and similar patterns in C-Flute RSC corrugated carboard boxes. This case packaging machine features a compact footprint that allows you to save on your floor space. At the same time, its simplicity and ergonomic design will enable you to pack and prepare your products for shipping and stacking quickly and efficiently.

TT-1200T Features
-Speeds up to 20 RSC Cases/Minute
-Compact Overall Footprint
-Integrated Acrylic Tape Case Sealer
-Quick Changeover and Easy Operation


Operation Overview

Cases are picked from a 36” powered case magazine with a twin chain feed with shaft-mounted pressure plate and 1/8 H.P. drive motor with air clutch. A low-level sensor is included, and it signals operators to replenish the cases in the magazine. Reciprocating case feeder with vacuum cup case placers erects the cases on a servo-driven, lugged conveyor. Cases are processed through the machine utilizing a servo-driven, lugged case carrier system that supports the case from the front and the back to ensure squareness during product loading and case closing. Filled and sealed cartons are received lying flat, with the long dimension leading. Cartons enter into the collation system, where 12 (2x6) cartons are collated. The pick and place system positively places previously collated cartons into the case. Case flaps are closed using a series of stationery and servo-driven tuckers. Once the flaps are closed into place, the case is tape closed and discharged for further processing.

The TT-1200T features an overall compact footprint, so you can rest assured it will fit your floor space. Reliable and portable with simple operation and a user-friendly interface, TT-1200T will be up and running in no time, providing you with the best case-packing automation. Built from welded solid stainless steel with hinged cover panels and safety electrical interlocks, TT-1200T is a powerful and efficient case packer that meets the highest standards with state-of-the-art simplicity.

Increase your efficiency with TT-1200T Vertical Case Packer!

https://www.tminn.com

0:00 - Intro
0:37 – Carton Indexing & Race Track System
0:47 – Carton Collating
0:59 – Case Forming
1:18 – Pick-And-Place System & Case Loading
1:29 – Case Closing & Tape Sealing
