LAB599 TX 500 DISCOVERY AWSOME HF TRANSCEIVER

Описание: Ultra-Compact HF Transceiver Lab599 TX-500 Discovery
Built for explorers, the Lab599 TX-500 is made to perform in harsh conditions and remote places — without sacrificing performance or essential features.
The Lab599 Discovery TX-500 covers 160−6 meters amateur radio bands, all modes, with a maximum power output of 10 W. It comes with true desktop-radio features, like auto-notch, noise reduction, and RX/TX EQ. The transceiver has a built-in fast panadapter, for easier search for new contacts and evaluation of band conditions wherever you are, at any time.
Discovery TX-500 —highly energy­efficient portable transceiver.
For a portable transceiver, one of the important characteristics is the power consumption in the receive mode. TX-500 transceiver uses unique circuit solutions to reduce the current consumption from a 13.8 V source to 100 mA, which is a unique offer on the market. The highly efficient transmission path will also allow you to enjoy long battery life on the air.
Unique form-factor
The Lab599 Discovery unique form-factor allows you to operate from anywhere. The transceiver is only 30 mm thick, including knobs, weighing only 0.55 kg. Fold out the kickstands at the rear for use on a desktop or picnic table.
11 Discret RF bandpass filters
Discovery TX-500 has 11 discrete RF bandpass filters. The RF signal is only passed through one of the band-pass filters — any out-of-range signals are rejected.
Built-in Panadapter
The transceiver features a built-in high-performance panadapter, for better search for new contacts and evaluation of band conditions — wherever you are, at any time.
Aluminum alloy body
The transceiver's body is made of durable aluminum by the method of precision milling, to ensure a unique shock protection and provide good heat removal from the output part of the transmitter.
Well shielded inner units
To achieve high sensitivity of the transceiver, separate functional units are isolated from mutual influence and external interference by partitioning walls installed in the device case.
Due to the liquid-protected housing and the absence of through-holes, spatter resistant plugs, encoders with sealing rings, the transceiver will work reliably in extreme conditions, giving you real pleasure from traveling.
Dust and liquid protection
The case is also covered with a layer of black anodizing substance, to maintain an attractive appearance for a long time, even during extreme operation.

The display of the transceiver is protected by 1 mm thick tempered glass resistant to scratches.
Software-Defined Radio
General receive coverage 0.5 – 56.0 MHz
Adjustable Output Power 1 – 10 W
Digital Hi-Performance Filtering (4 receive, 2 transmit)
48 kHz Build-in Hi-Speed Panadapter
I/Q Output and Firmware Update via USB
CW and Voice Messages Memory
CW and Voice Beacon Mode
Antenna SWR Monitor

GENERAL FEATURES
160-6-meter amateur radio bands
General ‘receive’ coverage 0.5 - 56.0 MHz
All modes: SSB, CW, DIG, AM, FM
High-performance 32-bit floating-point DSP
Current drain as low as 100 mA in ‘receive’ mode (backlight on, preamp off, no signal)
External power supply DC 9-15V, 1 to 3A typical in transmit
High-contrast LCD with 256×128px
High-performance real-time panadapter (48 kHz wide)
One-click online firmware upgrades

APPEARANCE AND DIMENSIONS
Ultra-compact size (H×W×D): 90 mm (3.5") × 207 mm (8.1") × 21 mm
Rear folding kickstands for viewing angle and transportation
Weight: 0.55 Kg (19,4 oz)
