How to Design Pile Caps & Pad Foundations in MasterSeries (to EuroCodes and British Standards)

Описание: 🏷️ Get Prices Here 🏷️
https://bit.ly/MasterSeries-2023-PDF-...

📥 Download our FREE 14 day MasterSeries trial using the following link 📥
https://www.masterseries.com/free-trial

📜 CPD Certificates 📜
https://forms.office.com/e/BzhQ7LukHN

MasterSeries allows for the integration of both Pad Foundation and Pile Cap Designs within our 3d modelling environment 'MasterFrame'.

Watch the recording of our latest webinar and learn how we can take the MasterFrame analytical model which calculates our support reactions with all the different load cases and combinations to allow for the design of a #reinforced and #unreinforced pad #foundation and #pilecap to #eurocode 2 #ec2 and #eurocode7 #ec7 and #britishstandards. We also give an introduction on some basic rules and geometrical parameters using various #istructe and #concrete center publications for reference.

We now offer #CPD #Certificates retrospectively, just watch the video and fill out the following quiz and we will batch issue monthly -


🧱 MasterKey: Concrete Pad Design 🧱
https://www.masterseries.com/products...

🏗️ MasterKey: Pile Cap Design🏗️
https://www.masterseries.com/products...

Key points/topics covered:
Creating a reinforced concrete retaining wall
Forces on a retaining wall
Types of failure of a retaining wall
Reinforcement in a retaining wall
Exporting detailed AutoCAD drawing
… and more


⏰ Timecodes ⏰
00:00 Webinar Introduction
02:20 Introduction to Pile Caps and Pad Foundations
03:05 Pile Cap Basic Geometrical Setting Out Rules and Parameters
07:50 Strut and Tie Model Method for Pile Cap Design
11:05 Pad Foundations Basic Rules and Parameters
12:25 Unreinforced Mass Concrete Pad Foundations
16:10 Analysis and Support Reactions within MasterFrame
18:00 MasterSeries Integrated Concrete Pad Foundation Design
18:38 Common Global Concrete Basic Data Design Settings
22:15 MasterKey: Concrete Pad Foundation Design Module
23:55 Concrete Pad Reinforcement
26:15 Offset Columns
27:00 Additional Pad Surcharge and Wall Loading
29:20 Concrete Pad Design Groups
33:28 MasterKey: Pile Cap Design Module - Capacity and Loading, Reinforcement, Briefs and Design Methodology
37:38 Pile Cap Reinforcement
39:05 Offset Pile Cap
41:10 Exporting Pile Cap Reinforcement Details and Schedule
42:18 Outro

📖 You can read more about MasterKey: Pile Cap and Concrete Design
topics via our blog here 📖
https://www.masterseries.com/blog/cat...
https://www.masterseries.com/blog/cat...
